| Parameter | HW-450S (6.6m Mast) | HW-450S (3.6m Mast) |
| Model | HW-450S | HW-450S |
| Mast Height | 6.6 meters | 3.6 meters |
| Engine Brand | Yuchai Power | Yuchai Power |
| Power | 110 kW | 110 kW |
| Main Pump | — | — |
| Max Drilling Depth | 450 m | 450 m |
| Drilling Diameter | 105–400 mm | 105–400 mm |
| Working Air Pressure | 1.2–3.5 MPa | 1.2–3.5 MPa |
| Air Consumption | 16–55 m³/min | 16–55 m³/min |
| Drill Rod Length | 6 m | 3 m |
| Drill Rod Diameter | Φ89 / Φ102 | Φ89 / Φ102 |
| Lifting Force | 3 t lifting capacity 20 t | 3 t lifting capacity 20 t |
| Slow Lifting Speed | — | — |
| Fast Lifting Speed | 30–55 m/min | 30–55 m/min |
| Rotary Torque | 9000/4500Nm | 9000/4500Nm |
| Rotary Speed | 0-90r/min；0-180r/min | 0-90r/min；0-180r/min |
| Drilling Efficiency | 10–35 m/h | 10–35 m/h |
| Travel Speed | 2.5 m | 2.5 m |
| Climbing Ability | 21° | 21° |
| Machine Weight | 8.5 t | 8.5 t |
| Dimensions (L×W×H) | 5.85×1.8×2.4m | 5.85×1.8×2.4m |
| Applicable Strata | Loose layers and bedrock | Loose layers and bedrock |
| Drilling Method | Down-the-hole (DTH) hammer | Down-the-hole (DTH) hammer |
| Equipped Hammer | High air pressure series | High air pressure series |
Get the Best Water Well Drilling Rig for Your Projects!
Discover our range of water well drilling rigs, designed to offer efficiency and durability in every drilling operation.
Fill out the form below to receive a personalized quote and expert advice with no obligation.
Why Choose Us?
Transparent Pricing: Receive a clear and detailed quote.
High Quality: Robust and reliable tools for any project.
Fast Shipping: Get your drilling rig in the shortest possible time.
After-Sales Service: Ongoing support and effective solutions.
Don’t wait any longer! Fill out the form and start drilling with the best technology.
Comprehensive Quality Guarantee:
24/7 Customer Support:
Regular Follow-Up and Maintenance Advice:
End-to-End Logistics Support:Please fill out the form below according to your needs, and our product specialist will contact you within one day.
