| Model | HW-750S |
| Engine | Weichai 176KW (China Stage III) / Cummins 154KW (China Stage III) |
| Power | 176KW / 154KW |
| Main Pump | Plunger Pump |
| Max Drilling Depth | 750m |
| Drilling Diameter | 105～450mm |
| Working Air Pressure | 1.6～6 MPa |
| Air Consumption | 16-75 m³/min |
| Drill Pipe Length | 6m |
| Drill Pipe Diameter | Φ102/Φ108/Φ114mm |
| Hoisting Capacity | 7t / Lifting capacity： 42t |
| Slow lifting speed | 6m/min / Slow feed speed：0.5-7m/min |
| Rapid lifting speed | 32m/min / Rapid feed speed：65m/min |
| Rotation Torque | 12600/6300Nm |
| Rotation Speed | 0-110r/min; 0-220r/min |
| Drilling Efficiency | 10-35m/h |
| Walking Speed | 3Km/h |
| Climbing Ability | 21° |
| Machine Weight | 14t |
| Dimensions (L×W×H) | 6.3×2.25×2.65m |
| Suitable Terrain | Loose strata and bedrock |
| Drilling Method | DTH impactor drilling |
| Hammer Type | High air pressure series |
Get the Best Water Well Drilling Rig for Your Projects!
Discover our range of water well drilling rigs, designed to offer efficiency and durability in every drilling operation.
Fill out the form below to receive a personalized quote and expert advice with no obligation.
Why Choose Us?
Transparent Pricing: Receive a clear and detailed quote.
High Quality: Robust and reliable tools for any project.
Fast Shipping: Get your drilling rig in the shortest possible time.
After-Sales Service: Ongoing support and effective solutions.
Don’t wait any longer! Fill out the form and start drilling with the best technology.
Comprehensive Quality Guarantee:
24/7 Customer Support:
Regular Follow-Up and Maintenance Advice:
End-to-End Logistics Support:Please fill out the form below according to your needs, and our product specialist will contact you within one day.
