Hengwang Hydraulic Drilling Rig Series
Hengwang Group hydraulic drilling rig is a professional water well drilling equipment, mainly used for industrial drilling, low temperature drilling and agricultural drilling. Wireline coring rigs can be used for geological exploration as well as SPT soil testing.
>>> Product Details <<<
Main feature:
1. Adopt hydraulic automatic drilling mechanism to improve drilling efficiency and reduce labor intensity;
2. Hengwang water well drilling rig is specially designed for the perfect match between the engine and the hydraulic system, which improves performance and reduces fuel consumption by 7%;
3. The fuselage design is compact and lightweight, which can work in plains and mountainous areas with less damage to vegetation.
| XY-44A | |||
| Drill rod category | Drill rod specifications (mm) | Drilling depth (m) | |
| Drill rod | Inside and outside flat | 42 | 1400 |
| 50 | 1000 | ||
| 60 | 830 | ||
| Cord coring | 55.5 | 1250 | |
| 71 | 1000 | ||
| 89 | 800 | ||
| DCDMA Drill rod | Cord coring | BQ drill rod | 1300 |
| NQ drill rod | 1000 | ||
| HQ drill rod | 750 | ||
| PQ drill rod | 420 | ||
| outside Thickening type | 60mm | 800 | |
| 73mm | 500 | ||
| 89mm | 300 | ||
Remark:
This product is continuously improved as technology advances. The difference between the parameters and the actual product is subject to the actual product.
Submit the form for more parameters and quotes.
